CATD系列
| 产品型号 | 标准输入 | 输入电压 | 输出电压 | 输出电流 | 纹波和噪声 | 效率 |
| CATD1000-220S24 | 220 | 176-264 | 24 | 41.67 | 200 | 85 |
| CATD1000-220S28 | 220 | 176-264 | 28 | 35.71 | 200 | 86 |
| CATD1000-220S36 | 220 | 176-264 | 36 | 27.78 | 250 | 87 |
| CATD1000-220S48 | 220 | 176-264 | 48 | 20.83 | 300 | 88 |
| CATD1000-220S110 | 220 | 176-264 | 110 | 9.09 | 300 | 87 |
| CATD1000-220S220 | 220 | 176-264 | 220 | 4.54 | 500 | 88 |
| CATD1200-220S24 | 220 | 176-264 | 24 | 50 | 200 | 88 |
| CATD1200-220S28 | 220 | 176-264 | 28 | 42.86 | 200 | 87 |
| CATD1200-220S36 | 220 | 176-264 | 36 | 33.33 | 250 | 88 |
| CATD1200-220S48 | 220 | 176-264 | 48 | 25 | 300 | 86 |
| CATD1200-220S110 | 220 | 176-264 | 110 | 10.91 | 300 | 87 |
| CATD1200-220S220 | 220 | 176-264 | 220 | 5.45 | 500 | 88 |
| CATD1500-220S24 | 220 | 176-264 | 24 | 62.5 | 200 | 85 |
| CATD1500-220S28 | 220 | 176-264 | 28 | 53.57 | 200 | 86 |
| CATD1500-220S36 | 220 | 176-264 | 36 | 41.67 | 250 | 87 |
| CATD1500-220S48 | 220 | 176-264 | 48 | 31.25 | 300 | 88 |
| CATD1500-220S110 | 220 | 176-264 | 110 | 13.64 | 300 | 87 |
| CATD1500-220S220 | 220 | 176-264 | 220 | 6.82 | 500 | 88 |
| CATD1800-220S36 | 220 | 176-264 | 36 | 50 | 250 | 86 |
| CATD1800-220S48 | 220 | 176-264 | 48 | 37.5 | 300 | 87 |
| CATD1800-220S60 | 220 | 176-264 | 60 | 30 | 300 | 88 |
| CATD1800-220S72 | 220 | 176-264 | 72 | 25 | 300 | 85 |
| CATD1800-220S110 | 220 | 176-264 | 110 | 16.36 | 300 | 86 |
| CATD1800-220S220 | 220 | 176-264 | 220 | 8.18 | 500 | 87 |
| CATD2000-220S36 | 220 | 176-264 | 36 | 55.55 | 250 | 86 |
| CATD2000-220S48 | 220 | 176-264 | 48 | 41.67 | 300 | 87 |
| CATD2000-220S60 | 220 | 176-264 | 60 | 33.33 | 300 | 88 |
| CATD2000-220S72 | 220 | 176-264 | 72 | 27.78 | 300 | 85 |
| CATD2000-220S110 | 220 | 176-264 | 110 | 18.18 | 300 | 86 |
| CATD2000-220S220 | 220 | 176-264 | 220 | 9.09 | 500 | 87 |
| CATD1000-220D12&12 | 220 | 176-264 | 12&12 | 41.67/41.67 | 120/120 | 87 |
| CATD1000-220D12&24 | 220 | 176-264 | 12&24 | 27.77/27.77 | 120/200 | 88 |
| CATD1000-220D24&24 | 220 | 176-264 | 24&24 | 20.83/20.83 | 200/200 | 86 |
| CATD1000-220D24&48 | 220 | 176-264 | 24&48 | 13.88/13.88 | 200/300 | 87 |
| CATD1000-220D48&48 | 220 | 176-264 | 48&48 | 10.42/10.42 | 300/300 | 88 |
| CATD1200-220D12&12 | 220 | 176-264 | 12&12 | 50/50 | 120/120 | 84 |
| CATD1200-220D12&24 | 220 | 176-264 | 12&24 | 33.33/33.33 | 120/200 | 85 |
| CATD1200-220D24&24 | 220 | 176-264 | 24&24 | 25/25 | 200/200 | 85 |
| CATD1200-220D24&48 | 220 | 176-264 | 24&48 | 16.67/16.67 | 200/300 | 84 |
| CATD1200-220D48&48 | 220 | 176-264 | 48&48 | 12.5/12.5 | 300/300 | 86 |
| CATD1500-220D12&12 | 220 | 176-264 | 12&12 | 62.5/62.5 | 120/120 | 84 |
| CATD1500-220D12&24 | 220 | 176-264 | 12&24 | 41.67/41.67 | 120/200 | 85 |
| CATD1500-220D24&24 | 220 | 176-264 | 24&24 | 31.25/31.25 | 200/200 | 85 |
| CATD1500-220D24&48 | 220 | 176-264 | 24&48 | 20.83/20.83 | 200/300 | 84 |
| CATD1500-220D48&48 | 220 | 176-264 | 48&48 | 15.63/15.63 | 300/300 | 86 |
| CATD2000-220D24&24 | 220 | 176-264 | 24&24 | 41.67/41.67 | 120/120 | 84 |
| CATD2000-220D24&48 | 220 | 176-264 | 24&48 | 25/29.17 | 120/200 | 85 |
| CATD2000-220D48&48 | 220 | 176-264 | 48&48 | 20.83/20.83 | 200/200 | 85 |
| CATD2000-220D60&60 | 220 | 176-264 | 60&60 | 16.67/16.67 | 200/300 | 84 |
| CATD2000-220D110&110 | 220 | 176-264 | 110&110 | 9.09/9.09 | 300/300 | 86 |
