CDAZ系列
| 产品型号 | 标准输入 | 输入电压 | 输出电压 | 输出电流 | 纹波和噪声 | 效率 |
| CDAZ40-12S05 | 12 | 9-18 | 5 | 8 | 50 | 82 |
| CDAZ40-12S12 | 12 | 9-18 | 12 | 3.33 | 120 | 82 |
| CDAZ40-12S15 | 12 | 9-18 | 15 | 2.67 | 150 | 82 |
| CDAZ40-12S24 | 12 | 9-18 | 24 | 1.67 | 200 | 83 |
| CDAZ40-12S36 | 12 | 9-18 | 36 | 1.11 | 300 | 83 |
| CDAZ40-12S48 | 12 | 9-18 | 48 | 0.83 | 300 | 84 |
| CDAZ50-12S05 | 12 | 9-18 | 5 | 10 | 50 | 83 |
| CDAZ50-12S12 | 12 | 9-18 | 12 | 4.17 | 120 | 83 |
| CDAZ50-12S24 | 12 | 9-18 | 24 | 2.08 | 200 | 84 |
| CDAZ50-12S48 | 12 | 9-18 | 48 | 1.04 | 300 | 84 |
| CDAZ40-24S05 | 24 | 18-36 | 5 | 8 | 50 | 82 |
| CDAZ40-24S24 | 24 | 18-36 | 12 | 3.33 | 120 | 82 |
| CDAZ40-24S15 | 24 | 18-36 | 15 | 2.67 | 150 | 82 |
| CDAZ40-24S24 | 24 | 18-36 | 24 | 1.67 | 200 | 83 |
| CDAZ40-24S36 | 24 | 18-36 | 36 | 1.11 | 300 | 83 |
| CDAZ40-24S48 | 24 | 18-36 | 48 | 0.83 | 300 | 84 |
| CDAZ50-24S05 | 24 | 18-36 | 5 | 10 | 50 | 83 |
| CDAZ50-24S24 | 24 | 18-36 | 12 | 4.17 | 120 | 83 |
| CDAZ50-24S24 | 24 | 18-36 | 24 | 2.08 | 200 | 84 |
| CDAZ50-24S48 | 24 | 18-36 | 48 | 1.04 | 300 | 84 |
| CDAZ40-48S05 | 48 | 36-72 | 5 | 8 | 50 | 82 |
| CDAZ40-48S48 | 48 | 36-72 | 12 | 3.33 | 120 | 82 |
| CDAZ40-48S15 | 48 | 36-72 | 15 | 2.67 | 150 | 82 |
| CDAZ40-48S24 | 48 | 36-72 | 24 | 1.67 | 200 | 83 |
| CDAZ40-48S36 | 48 | 36-72 | 36 | 1.11 | 300 | 83 |
| CDAZ40-48S48 | 48 | 36-72 | 48 | 0.83 | 300 | 84 |
| CDAZ50-48S05 | 48 | 36-72 | 5 | 10 | 50 | 83 |
| CDAZ50-48S48 | 48 | 36-72 | 12 | 4.17 | 120 | 83 |
| CDAZ50-48S24 | 48 | 36-72 | 24 | 2.08 | 200 | 84 |
| CDAZ50-48S48 | 48 | 36-72 | 48 | 1.04 | 300 | 84 |
| CDAZ40-110S05 | 110 | 66-160 | 5 | 8 | 50 | 82 |
| CDAZ40-110S110 | 110 | 66-160 | 12 | 3.33 | 120 | 82 |
| CDAZ40-110S15 | 110 | 66-160 | 15 | 2.67 | 150 | 82 |
| CDAZ40-110S24 | 110 | 66-160 | 24 | 1.67 | 200 | 83 |
| CDAZ40-110S36 | 110 | 66-160 | 36 | 1.11 | 300 | 83 |
| CDAZ40-110S48 | 110 | 66-160 | 48 | 0.83 | 300 | 84 |
| CDAZ50-110S05 | 110 | 66-160 | 5 | 10 | 50 | 83 |
| CDAZ50-110S110 | 110 | 66-160 | 12 | 4.17 | 120 | 83 |
| CDAZ50-110S24 | 110 | 66-160 | 24 | 2.08 | 200 | 84 |
| CDAZ50-110S48 | 110 | 66-160 | 48 | 1.04 | 300 | 84 |
| CDAZ40-300S05 | 300 | 200-400 | 5 | 8 | 50 | 82 |
| CDAZ40-300S300 | 300 | 200-400 | 12 | 3.33 | 120 | 82 |
| CDAZ40-300S15 | 300 | 200-400 | 15 | 2.67 | 150 | 82 |
| CDAZ40-300S24 | 300 | 200-400 | 24 | 1.67 | 200 | 83 |
| CDAZ40-300S36 | 300 | 200-400 | 36 | 1.11 | 300 | 83 |
| CDAZ40-300S48 | 300 | 200-400 | 48 | 0.83 | 300 | 84 |
| CDAZ50-300S05 | 300 | 200-400 | 5 | 10 | 50 | 83 |
| CDAZ50-300S300 | 300 | 200-400 | 12 | 4.17 | 120 | 83 |
| CDAZ50-300S24 | 300 | 200-400 | 24 | 2.08 | 200 | 84 |
| CDAZ50-300S48 | 300 | 200-400 | 48 | 1.04 | 300 | 84 |
