CDCD系列
| 产品型号 | 标准输入 | 输入电压 | 输出电压 | 输出电流 | 纹波和噪声 | 效率 |
| CDCD75-12D05&05 | 12 | 9-18 | 05&05 | 7.5/7.5 | 50/50 | 83 |
| CDCD75-12D05&12 | 12 | 9-18 | 05&12 | 5/4.17 | 50/120 | 85 |
| CDCD75-12T12&05 | 12 | 9-18 | ±12&05 | 2.5/2.5/3 | 120/120/50 | 84 |
| CDCD75-12T15&05 | 12 | 9-18 | ±15&05 | 3.33/1/2 | 150/150/50 | 85 |
| CDCD75-12T12&12 | 12 | 9-18 | ±12&12 | 1.46/1.46/3.33 | 120/120/120 | 86 |
| CDCD100-12D12&12 | 12 | 9-18 | 12&12 | 4.17/4.17 | 120/120 | 85 |
| CDCD100-12D12&24 | 12 | 9-18 | 12&24 | 2.5/2.92 | 120/200 | 86 |
| CDCD100-12D24&24 | 12 | 9-18 | 24&24 | 2/2 | 200/200 | 87 |
| CDCD100-12T12&05 | 12 | 9-18 | ±12&05 | 2.08/2.08/5 | 120/120/50 | 85 |
| CDCD100-12T15&05 | 12 | 9-18 | ±15&05 | 2.67/2.67/4 | 150/150/50 | 85 |
| CDCD100-12T12&12 | 12 | 9-18 | ±12&12 | 2.5/2.5/3.33 | 120/120/120 | 86 |
| CDCD125-12D24&24 | 12 | 9-18 | 24&24 | 2.6/2.6 | 200/200 | 86 |
| CDCD125-12D24&48 | 12 | 9-18 | 24&48 | 2.6/1.3 | 200/300 | 87 |
| CDCD125-12T12&05 | 12 | 9-18 | ±12&05 | 3.5/3.5/8 | 120/120/50 | 85 |
| CDCD125-12T15&05 | 12 | 9-18 | ±15&05 | 2.83/2.83/8 | 150/150/50 | 86 |
| CDCD125-12T12&12 | 12 | 9-18 | ±12&12 | 2.7/2.7/5 | 120/120/120 | 86 |
| CDCD75-24D05&05 | 24 | 18-36 | 05&05 | 7.5/7.5 | 50/50 | 84 |
| CDCD75-24D05&12 | 24 | 18-36 | 05&12 | 5/4.17 | 50/120 | 86 |
| CDCD75-24T12&05 | 24 | 18-36 | ±12&05 | 2.5/2.5/3 | 120/120/50 | 86 |
| CDCD75-24T15&05 | 24 | 18-36 | ±15&05 | 3.33/1/2 | 150/150/50 | 86 |
| CDCD75-24T12&12 | 24 | 18-36 | ±12&12 | 1.46/1.46/3.33 | 120/120/120 | 87 |
| CDCD100-24D12&12 | 24 | 18-36 | 12&12 | 4.17/4.17 | 120/120 | 86 |
| CDCD100-24D12&24 | 24 | 18-36 | 12&24 | 2.5/2.92 | 120/200 | 87 |
| CDCD100-24D24&24 | 24 | 18-36 | 24&24 | 2/2 | 200/200 | 88 |
| CDCD100-24T12&05 | 24 | 18-36 | ±12&05 | 2.08/2.08/5 | 120/120/50 | 86 |
| CDCD100-24T15&05 | 24 | 18-36 | ±15&05 | 2.67/2.67/4 | 150/150/50 | 87 |
| CDCD100-24T12&12 | 24 | 18-36 | ±12&12 | 2.5/2.5/3.33 | 120/120/120 | 87 |
| CDCD125-24D24&24 | 24 | 18-36 | 24&24 | 2.6/2.6 | 200/200 | 87 |
| CDCD125-24D24&48 | 24 | 18-36 | 24&48 | 2.6/1.3 | 200/300 | 88 |
| CDCD125-24T12&05 | 24 | 18-36 | ±12&05 | 3.5/3.5/8 | 120/120/50 | 86 |
| CDCD125-24T15&05 | 24 | 18-36 | ±15&05 | 2.83/2.83/8 | 150/150/50 | 87 |
| CDCD125-24T12&12 | 24 | 18-36 | ±12&12 | 2.7/2.7/5 | 120/120/120 | 87 |
| CDCD75-48D05&05 | 48 | 36-72 | 05&05 | 7.5/7.5 | 50/50 | 84 |
| CDCD75-48D05&12 | 48 | 36-72 | 05&12 | 5/4.17 | 50/120 | 86 |
| CDCD75-48T12&05 | 48 | 36-72 | ±12&05 | 2.5/2.5/3 | 120/120/50 | 86 |
| CDCD75-48T15&05 | 48 | 36-72 | ±15&05 | 3.33/1/2 | 150/150/50 | 86 |
| CDCD75-48T12&12 | 48 | 36-72 | ±12&12 | 1.46/1.46/3.33 | 120/120/120 | 87 |
| CDCD100-48D12&12 | 48 | 36-72 | 12&12 | 4.17/4.17 | 120/120 | 86 |
| CDCD100-48D12&24 | 48 | 36-72 | 12&24 | 2.5/2.92 | 120/200 | 87 |
| CDCD100-48D24&24 | 48 | 36-72 | 24&24 | 2/2 | 200/200 | 88 |
| CDCD100-48T12&05 | 48 | 36-72 | ±12&05 | 2.08/2.08/5 | 120/120/50 | 86 |
| CDCD100-48T15&05 | 48 | 36-72 | ±15&05 | 2.67/2.67/4 | 150/150/50 | 87 |
| CDCD100-48T12&12 | 48 | 36-72 | ±12&12 | 2.5/2.5/3.33 | 120/120/120 | 87 |
| CDCD125-48D24&24 | 48 | 36-72 | 24&24 | 2.6/2.6 | 200/200 | 87 |
| CDCD125-48D24&48 | 48 | 36-72 | 24&48 | 2.6/1.3 | 200/300 | 88 |
| CDCD125-48T12&05 | 48 | 36-72 | ±12&05 | 3.5/3.5/8 | 120/120/50 | 86 |
| CDCD125-48T15&05 | 48 | 36-72 | ±15&05 | 2.83/2.83/8 | 150/150/50 | 87 |
| CDCD125-48T12&12 | 48 | 36-72 | ±12&12 | 2.7/2.7/5 | 120/120/120 | 87 |
