CDGZ系列
| 产品型号 | 标准输入 | 输入电压 | 输出电压 | 输出电流 | 纹波和噪声 | 效率 |
| CDGZ100-12S05 | 12 | 9-18 | 5 | 20 | 50 | 83 |
| CDGZ100-12S12 | 12 | 9-18 | 12 | 8.33 | 120 | 84 |
| CDGZ100-12S24 | 12 | 9-18 | 24 | 4.17 | 200 | 85 |
| CDGZ100-12S48 | 12 | 9-18 | 48 | 2.08 | 300 | 86 |
| CDGZ100-12D05+05 | 12 | 9-18 | 05+05 | 10/10 | 50/50 | 84 |
| CDGZ100-12D05+12 | 12 | 9-18 | 05+12 | 6/5.83 | 50/120 | 84 |
| CDGZ100-12D05+24 | 12 | 9-18 | 05+24 | 4/3.33 | 50/200 | 85 |
| CDGZ100-12D12+12 | 12 | 9-18 | 12+12 | 4.17/4.17 | 120/120 | 86 |
| CDGZ100-12D12+24 | 12 | 9-18 | 12+24 | 2.5/2.92 | 120/200 | 86 |
| CDGZ100-12D24+24 | 12 | 9-18 | 24+24 | 2.08/2.08 | 200/200 | 86 |
| CDGZ75-12T05&12 | 12 | 9-18 | ±05&12 | 3/3/3.75 | 50/50/120 | 84 |
| CDGZ75-12T12&05 | 12 | 9-18 | ±12&05 | 1.67/1.67/7 | 120/120/50 | 84 |
| CDGZ75-12T15&05 | 12 | 9-18 | ±15&05 | 2/2/3 | 150/150/50 | 84 |
| CDGZ100-24S05 | 24 | 18-36 | 5 | 20 | 50 | 84 |
| CDGZ150-24S12 | 24 | 18-36 | 12 | 12.5 | 120 | 85 |
| CDGZ150-24S24 | 24 | 18-36 | 24 | 6.25 | 200 | 86 |
| CDGZ150-24S48 | 24 | 18-36 | 48 | 3.13 | 300 | 87 |
| CDGZ150-24D05+12 | 24 | 18-36 | 05+12 | 10/8.33 | 50/120 | 86 |
| CDGZ150-24D05+24 | 24 | 18-36 | 05+24 | 6/5 | 50/200 | 86 |
| CDGZ150-24D12+12 | 24 | 18-36 | 12+12 | 6.25/6.25 | 120/120 | 86 |
| CDGZ150-24D12+24 | 24 | 18-36 | 12+24 | 4.17/4.17 | 120/200 | 87 |
| CDGZ150-24D24+24 | 24 | 18-36 | 24+24 | 3.13/3.13 | 200/200 | 85 |
| CDGZ100-24T05&12 | 24 | 18-36 | ±05&12 | 4/4/5 | 50/50/120 | 85 |
| CDGZ100-24T12&05 | 24 | 18-36 | ±12&05 | 2.5/2.5/8 | 120/120/50 | 86 |
| CDGZ100-24T15&05 | 24 | 18-36 | ±15&05 | 2/2/4 | 150/150/50 | 86 |
| CDGZ100-48S05 | 48 | 36-72 | 5 | 20 | 50 | 84 |
| CDGZ150-48S12 | 48 | 36-72 | 12 | 12.5 | 120 | 85 |
| CDGZ150-48S24 | 48 | 36-72 | 24 | 6.25 | 200 | 86 |
| CDGZ150-48S48 | 48 | 36-72 | 48 | 3.13 | 300 | 87 |
| CDGZ150-48D05+12 | 48 | 36-72 | 05+12 | 10/8.33 | 50/120 | 86 |
| CDGZ150-48D05+24 | 48 | 36-72 | 05+24 | 6/5 | 50/200 | 86 |
| CDGZ150-48D12+12 | 48 | 36-72 | 12+12 | 6.25/6.25 | 120/120 | 86 |
| CDGZ150-48D12+24 | 48 | 36-72 | 12+24 | 4.17/4.17 | 120/200 | 87 |
| CDGZ150-48D24+24 | 48 | 36-72 | 24+24 | 3.13/3.13 | 200/200 | 85 |
| CDGZ100-48T05&12 | 48 | 36-72 | ±05&12 | 4/4/5 | 50/50/120 | 85 |
| CDGZ100-48T12&05 | 48 | 36-72 | ±12&05 | 2.5/2.5/8 | 120/120/50 | 86 |
| CDGZ100-48T15&05 | 48 | 36-72 | ±15&05 | 2/2/4 | 150/150/50 | 86 |
| CDGZ100-110S05 | 110 | 66-160 | 5 | 20 | 50 | 83 |
| CDGZ100-110S12 | 110 | 66-160 | 12 | 8.33 | 120 | 84 |
| CDGZ100-110S24 | 110 | 66-160 | 24 | 4.17 | 200 | 85 |
| CDGZ100-110S48 | 110 | 66-160 | 48 | 2.08 | 300 | 86 |
| CDGZ100-110D05+12 | 110 | 66-160 | 05+12 | 6/5.83 | 50/120 | 84 |
| CDGZ100-110D05+24 | 110 | 66-160 | 05+24 | 4/3.33 | 50/200 | 84 |
| CDGZ100-110D12+12 | 110 | 66-160 | 12+12 | 4.17/4.17 | 120/120 | 85 |
| CDGZ100-110D12+24 | 110 | 66-160 | 12+24 | 2.5/2.92 | 120/200 | 86 |
| CDGZ100-110D24+24 | 110 | 66-160 | 24+24 | 2.08/2.08 | 200/200 | 86 |
| CDGZ100-110D24+48 | 110 | 66-160 | 24+48 | 3.33/3.33 | 200/300 | 86 |
| CDGZ75-110T05&12 | 110 | 66-160 | ±05&12 | 3/3/3.75 | 50/50/120 | 84 |
| CDGZ75-110T12&05 | 110 | 66-160 | ±12&05 | 1.67/1.67/7 | 120/120/50 | 84 |
| CDGZ75-110T15&05 | 110 | 66-160 | ±15&05 | 2/2/3 | 150/150/50 | 84 |
