RDFZ系列
| 产品型号 | 标准输入 | 输入电压 | 输出电压 | 输出电流 | 纹波和噪声 | 效率 |
| RDFZ75-12S05 | 12 | 9-18 | 5 | 15 | 50 | 82 |
| RDFZ75-12S12 | 12 | 9-18 | 12 | 6.25 | 120 | 83 |
| RDFZ75-12S15 | 12 | 9-18 | 15 | 5 | 150 | 83 |
| RDFZ75-12S24 | 12 | 9-18 | 24 | 3.13 | 200 | 84 |
| RDFZ75-12S48 | 12 | 9-18 | 48 | 1.56 | 300 | 85 |
| RDFZ100-12S12 | 12 | 9-18 | 12 | 8.33 | 120 | 83 |
| RDFZ100-12S24 | 12 | 9-18 | 24 | 4.17 | 200 | 84 |
| RDFZ100-12S48 | 12 | 9-18 | 48 | 2.08 | 300 | 85 |
| RDFZ75-24S05 | 24 | 18-36 | 5 | 15 | 50 | 83 |
| RDFZ75-24S12 | 24 | 18-36 | 12 | 6.25 | 120 | 84 |
| RDFZ75-24S15 | 24 | 18-36 | 15 | 5 | 150 | 84 |
| RDFZ75-24S24 | 24 | 18-36 | 24 | 3.13 | 200 | 85 |
| RDFZ75-24S48 | 24 | 18-36 | 48 | 1.56 | 300 | 86 |
| RDFZ100-24S12 | 24 | 18-36 | 12 | 8.33 | 120 | 85 |
| RDFZ100-24S24 | 24 | 18-36 | 24 | 4.17 | 200 | 85 |
| RDFZ100-24S48 | 24 | 18-36 | 48 | 2.08 | 300 | 86 |
| RDFZ75-48S05 | 48 | 36-72 | 5 | 15 | 50 | 83 |
| RDFZ75-48S12 | 48 | 36-72 | 12 | 6.25 | 120 | 84 |
| RDFZ75-48S15 | 48 | 36-72 | 15 | 5 | 150 | 84 |
| RDFZ75-48S24 | 48 | 36-72 | 24 | 3.13 | 200 | 85 |
| RDFZ75-48S48 | 48 | 36-72 | 48 | 1.56 | 300 | 86 |
| RDFZ100-48S12 | 48 | 36-72 | 12 | 8.33 | 120 | 85 |
| RDFZ100-48S24 | 48 | 36-72 | 24 | 4.17 | 200 | 85 |
| RDFZ100-48S48 | 48 | 36-72 | 48 | 2.08 | 300 | 86 |
| RDFZ75-110S05 | 110 | 66-160 | 5 | 15 | 50 | 83 |
| RDFZ75-110S12 | 110 | 66-160 | 12 | 6.25 | 120 | 84 |
| RDFZ75-110S15 | 110 | 66-160 | 15 | 5 | 150 | 84 |
| RDFZ75-110S24 | 110 | 66-160 | 24 | 3.13 | 200 | 85 |
| RDFZ75-110S48 | 110 | 66-160 | 48 | 1.56 | 300 | 86 |
| RDFZ100-110S12 | 110 | 66-160 | 12 | 8.33 | 120 | 85 |
| RDFZ100-110S24 | 110 | 66-160 | 24 | 4.17 | 200 | 85 |
| RDFZ100-110S48 | 110 | 66-160 | 48 | 2.08 | 300 | 86 |
| RDFZ75-18S12 | 18 | 9-36 | 12 | 6.25 | 120 | 84 |
| RDFZ75-18S24 | 18 | 9-36 | 24 | 3.13 | 200 | 84 |
| RDFZ75-18S248 | 18 | 9-36 | 48 | 4.17 | 300 | 85 |
| RDFZ100-18S12 | 18 | 9-36 | 12 | 8.33 | 120 | 85 |
| RDFZ100-18S24 | 18 | 9-36 | 24 | 4.17 | 200 | 85 |
| RDFZ100-18S248 | 18 | 9-36 | 48 | 2.08 | 300 | 86 |
| RDFZ75-36S12 | 36 | 18-72 | 12 | 6.25 | 120 | 84 |
| RDFZ75-36S24 | 36 | 18-72 | 24 | 3.13 | 200 | 84 |
| RDFZ75-36S248 | 36 | 18-72 | 48 | 4.17 | 300 | 85 |
| RDFZ100-36S12 | 36 | 18-72 | 12 | 8.33 | 120 | 85 |
| RDFZ100-36S24 | 36 | 18-72 | 24 | 4.17 | 200 | 85 |
| RDFZ100-36S248 | 36 | 18-72 | 48 | 2.08 | 300 | 86 |
| RDFZ75-100S12 | 100 | 40-160 | 12 | 6.25 | 120 | 84 |
| RDFZ75-100S24 | 100 | 40-160 | 24 | 3.13 | 200 | 84 |
| RDFZ75-100S248 | 100 | 40-160 | 48 | 4.17 | 300 | 85 |
| RDFZ100-100S12 | 100 | 40-160 | 12 | 8.33 | 120 | 85 |
| RDFZ100-100S24 | 100 | 40-160 | 24 | 4.17 | 200 | 85 |
| RDFZ100-100S248 | 100 | 40-160 | 48 | 2.08 | 300 | 86 |
